Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material

Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material

  • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
  • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
  • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
  • Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material
รายละเอียดสินค้า:
Place of Origin: China
ชื่อแบรนด์: SINOTRUK
ได้รับการรับรอง: ISO/3C/BV/IFA/SGS
Model Number: 3 Axles 30-60Tons
การชำระเงิน:
Minimum Order Quantity: 1 Unit
ราคา: Negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on
Delivery Time: 20 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 4,000units per month
ติดต่อ
รายละเอียดสินค้า
Product Name: Refrigerated Semi Trailer Truck Model: 3 Axles 30-60Tons
Fifth Wheel: #50, #90 Loading capacity: 30-60tons
Dimension of Flat: 12600*3000mm Axles: 3X16 tons
Material: Carbon steel or Mn steel Landing gear: 28T JOST
แสงสูง:

semi flatbed trailers

,

hydraulic flatbed trailer

Refrigerated Semi Trailer Truck 20 or 40 Feet Container 2 or 3 Axles 30-60 Tons



Description:



Refrigerated Semi Trailer Truck 20 or 40 Feet Container 2 or 3 Axles 30-60 Tons

Refrigerated truck is one kind of closed van truck which is used to transport the frozen

or fresh goods, was fitted with the refrigerating unit device and polyurethane thermal

insulation van and it is refrigeration special use transport truck,



usually used for transporting frozen foods ( freezer truck ), dairy ( milk truck ), vegetables and fruits

( fresh goods transport vehicle ), vaccine and drug ( vaccine vehicles) etc.



Our company produces flat semitrailer divided into flat, concave beam and tire exposed structure,

beam adopts flat type or goose neck. The frame is ladder type, the beam cross-section is

I-shaped, has high anti breaking strength and bearing capacity.





Specification:



Refrigerated Semi Trailer Truck 20 or 40 Feet Container 2 or 3 Axles 30-60 Tons

Model 3 Axles 60Tons
Axle

FUWA brand, 16ton, 2 Sets

Main beam

Beam height: 500mm

Upper plate: 10mm

Double Middle plate: 6 mm

Down plate: 12mm

Dimension of cargo body

13000*2335*2390mm

Van board material

polymer composites

Gross vehicle weight

70000kgs

King pin

#90

Support leg

JOST Standard 28T

Suspension

Normal suspension

Thickness leaf spring

10/10/10

Tire/Rim

1200R20, 13pcs, 8.5, 12 pcs

Brake Chamber

Standard 6 pcs

Spare wheel carrier

2 pcs

Tool box

1 pcs

Electrical System

Chinese standard 24C lighting system

Side Maker Lamp

LED lamp

Painting

Polyurethane Paint

Overall dimension

16000×2500×3880(mm)

Color White, red, green, golden and so on.








Applications:



Refrigerated semi trailer Truck can widespread use in transportation of all kind of frozen food, vaccinum, vegetables and fruit.



Competitive Advantage:



1) competitive price, cost-effective

2) quick and efficient spare parts supply bring you more convenient

3) fast delivery time, we can arrange production according to your needs exactly and Quickly

4) professional import and export dealing procedure, make customs clearance more high efficiency

5) Refrigeration, heat preservation car body with light, high strength, good heat

insulation performance, high temperature stability, no pollution, oxidation, easy

maintenance, but also has low noise, low energy consumption, low failure rate, food

preservation effect is good and so on a series of advantages
6) A lot of technical indicators and the world's advanced level is close to the fully

closed polyurethane plate bonded glass steel structure, this product is light weight,

low heat leakage.

7) The "sandwich" structure (low thermal conductivity), good thermal

insulation effect. Using unsaturated polyester resin as binder, plus a cushion, with

rigid polyurethane foam insulation, heat conduction low coefficient, high strength. High

strength plate bonding, high sealing glue, forming a whole. The structure of the

refrigerator car is dominant in the domestic market, our company is using the technology

of refrigerated trucks.

8) Our company's production of circular easy brand refrigerator car introduced Italy,

Germany, the United States overall polyester foam technology, and high strength fiber

plastic and other material manufacturing technology and equipment
9) so that our company refrigeration, heat preservation technology level basic reached

world advanced water level.

10)Using three axis balance, double axis balance or rigid suspension, the mass balance block is

arranged between the front and rear leaf springs.

11) the key parts adopt the world's top technology products

12)based on strong technical support and top level technology make the trucks with high quality and

more reliable



Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material 0Semi Flatbed Trailers Refrigerated Transport Vehicle Carbon Steel / Mn Steel Material 1
